Galileo-tp pq electric appliance tester
For sale: Electrical safety tester equipment PQ Electric plus some add-ons, see pictures, in perfect condition.
PQ ELECTRIC designed to carry our electrical performance tests on domestic appliance.
The electrical safety test has been designed to carry our electrical performance tests on domestic appliance, according to the standards EN60204-1, EN60335-1, EN60335-2-24, EN61010-1 and EN 50106, after the refrigerant charge has been performed. The solid steel cabinet equipped with wheels makes it strong and agile at the same time. Work cycles can be easily programmed by an easy menu on a display, and the operator can decide the sequence and parameters to be used. Anyway, the programming phase is protected by a password. In details, the machine is able to test electrical insulation, ground bond, dielectric strength, short circuit, leakage current, active power and absorbed current as well as residual voltage.
Voltage supply: 230 Vac single phase: 50/60 Hz
Display: LCD graphic 128x240 (16x40 characters)
Equipment under test connection
Industrial female outlet (2 ph. + ground)
Programming: with easy menu, protected with password. The sequence of the test is completely programmable, and independent for each cycle
Data communication interface: Serial port (RS232) to connect a PC (PLC) and a bar code reader; Serial port (RS232) to connect to an external printer
Calibration box included: 2.002.2.061 (S/N3502-026)
This item is used in perfect condition, look like new, has been tested to be in good working condition.
This product can be previewed at our facility in Toronto, Canada, during normal business hours.
