> Clausing 8520/8525 vertical mill opertator/part manual
Clausing 8520/8525 vertical mill opertator/part manual
This is a reproduction, not a photocopy, of an original Clausing Vertical Mill 8520 & 8525 Instructions and Parts Manual, Plus Sales Catalog. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments for the mill. We added a catalog on the mill that is a great compliment to the manual. It covers setup and accessories like a lot of the old catalogs contained.
Clausing made two different vertical mills the 8520/8525 and the 8530/8535.
The mill pictured above is the 8520/8525. There are major differences in the knee and
Motor Recommendation.............................1
Machine Installation.............................2
Mounting Motor...................................2
Wiring...........................................2
Controls.........................................3
Lubrication......................................4
Spindle Speeds...................................4
Mounting Cutters.................................4
Head.............................................5
Over-Arm and Motor...............................6
Table and Cross Slide............................7
Knee.............................................8
Accuracy.....................................10,11
Specifications..................................12
Motors..........................................12
Optional Electrical Equipment...................12
Attachments and Accessories.....................13
Measuring Attachment............................14
Dimensions......................................14
