Ameritron rcs-4L(x) coax switch w/lightning protection
NEW AMERITRON RCS-4 L or RCS-4L(x) REMOTE COAX SWITCH
1.5-54 MHz with Lightning Protection
This is a new in the box RCS-4Lor RCS 4LX (European version)
The Ameritron RCS-4L or (X ) is a remote controlled coax switch that selects one of four outputs by supplying all control voltages through the coax. The elimination of control cables gives you a fast, neat and inexpensive installation with only one coaxial line for four antennas. The cable is not included with this unit.
You get two units - the switching box that can be tower, mast or wall mounted and the control console that is located at your operating station. The attractive indoor console has bright LED antenna selector indicators. A steel enclosure provides 100% shielding to prevent RFI and TVI. Switching time is 50ms. SO-239 connectors provide reliable connections. The weatherproof switching box uses three heavy duty 10 ampere contact relays on a rugged G-10 fiberglass circuit board. Quality components are used throughout the entire unit to ensure maximum life for the sometimes difficult-to-reach switching box.
another country before purchasing :
The RCS-4LX operates from 240 VAC power source that allows safe operation with 14 volts control voltage. Frequencies from 1.5 - 54 MHz are covered by this excellent station accessory. handles over 2.5 kw
* Number of antenna positions: 4
* Power Capability: 2.5 KW average continuous
* Control Box: 6 1/8"D x 5 1/4"W x 3 3/8" H
* Switch Box: 5 3/8"D x 7"W x 3"H
I have a duty free number for most countries for ham radio items. There would be
no custom duty tax, but, you will be responsible for the VAT tax, that is based on
- Import duties, taxes, and charges are NOT INCLUDED in the item price
- These charges are normally collected by the delivering freight
- We do not mark merchandise values below value or mark items as gifts,
Only US funds accepted. We are an authorized dealer and all our items are new in the box, come with a signed sales receipt and they also come with MFJ s great warranty. The warranty
We are a Texas store, if you reside in Texas, you will have to pay the Texas sales tax.
