Jet/asian 12" tilting arbor saw ctas-12H part manual
12-inch Tilting Table Saw CTAS-12H
This is a reproduction, not a photocopy, of an original JET CTAS-12H 12-inch Tilting Arbor Saw Instructions and Parts Manual. This manual contains general safety instructions, operation instructions, adjustments, maintenance, lubrication, and a complete set of exploded view diagrams of the parts with description. Please read the index below.
This machine was produced in Asia, and was sold under different brands. To help identify your machine I am posting a picture plus a specification sheet of the size and speeds of the machine. I do not have model numbers of the other companies that this machine was sold under. I have provided all the information I have. The only way I can help you find which manual fits your machine is to send me a picture by email to ****@ozarkwoodworker.com or postal mail.
Saw diameter..............................300mm (12in)
Dia.of saw arbor..........................25.4mm (1in)
Max.saw projection.....................105mm (4 1/8in)
Table dimension....................1070x860mm(42x34in)
Arbor tilting angle...............................0~45
Spindle speed..............................3,750r.p.m.
Power required......................3Hp 1ph or 5Hp 3ph
Net weight............................300kgs (660 lbs)
Gross weight..........................390kgs (860 lbs)
1. General Safety Precautions....................................1
2. Additional safety rules for tilting arbor table saws..........2
3. Unpacking and cleanup.........................................2
4. Assembling extension wings................................... 2
5. Instal lation and levelling.................................. 2
6. Assembling and aligning motor motor pulley and belt...........3
7. Assembling blade guard........................................3
8. Assembling guide rails........................................4
9. Miter gage operation and adjustment...........................4
10. Rip fence operation and adjustment...........................4
11. Adjusting miter gage slots parallel to saw blade.............5
12. Table insert adjustment......................................5
13. Adjusting 90 and 45 degree positive stop.....................5
14. Changing arbor extensions....................................5
15. Parts list............................................7,8,9,10
