Xantrex/sorensen dc power supply 6X 0-10V 0-30A DLM600
Xantrex/Sorensen DC Power Supply 6x 0-10V 0-30A DLM600
Testing notes: We applied power and disabled the interlock as explained in the included manual, and the unit turned on. After the computer finished booting, the MAIN PWR, all six INTERLOCK, and DEVICENET MODULE STATUS (Red) lights came on. After sitting for a minute and not finding anything connected to the DeviceNet port, all six of the FAULT lights came on, and the DEVICENET MODULE STATUS (Green) lights came on. If one of the output enable interlocks was set, that channel's INTERLOCK button would be OFF when the computer finished booting. We do not have a DNet control setup, so we were unable to program any of the outputs to turn on. No other testing was done.
* Input Power: 200-240VAC 3phase 15A(per leg) 50/60Hz
* Number Of Output Channels: 6
* Output Power (Per Channel): 0-10VDC (positive and negative), 0-30A, 300W (continuous)
* Control/Programming via DeviceNet
* Constant Voltage or Constant Current (CV/CC) Mode operation
* With Output Polarity Switch
* With Voltage & Current Peak Detection
* Charge Accumulator with Limit Setpoint
* Channel ON/OFF/Pause/Reset
* Channel Status Data: Voltage/Current value, Peak Voltage/Current value, Charge Value
* Soft Alarms (output not stopped)
* Hard Faults (output is stopped)
