Yaesu ft-8800R vhf/uhf dual band transceiver + mh-48A6J
This is original Yaesu FT-8800R Ultimate Dual Band Transceiver with FREE MH-48A6J original speaker mic. 100% new, factory packed and never been used.
The FT-8800 series provides extended receiver coverage beyond the Amateur bands, so you can keep informed of communications activities in the public safety, commercial, aircraft, and government communications ranges.
The FT-8800 series operates as two radios in one, with either 144 MHz or 430 MHz as the "Main" TX/RX band, with simultaneous monitoring of the other band. Each band has its own Volume and Squelch
controls, and you can configure your FT-8800 series for VHF-VHF or UHF-UHF operation, too!
To get your message through when it counts, the FT-8800 series puts out a full 50 Watts of power on the 144 MHz band, and 35 Watts on 430 MHz. A thermal sensor monitors heat sink temperature, engaging the rear
panel s cooling fan only when needed.
The FT-8800 series provides a wide variety of memory resources, including 512 "regular" memories each
bands, Five "Home" channels for favorite frequencies, Ten sets of band-edge memories each bands, and six
"Hyper Memories" which store complete sets of transceiver operating status.
Affording easy viewing from a wide variety of viewing angles, the LCD of the FT-8800 series features Yaesu s
renowned Omni-Glow display illumination, with four illuminations levels available for different operating
For emergency work, or to extend the range of a handheld unit, the FT-8800 series includes Cross-Band
Repeat capability, similar to that pioneered on our popular FT-8100 series Dual Band FM Mobile!
To save valuable time when operating a transceiver with the capability of the FT-8800 series, the "Hyper Memory" feature allows you to store a complete set of configuration data for the two bands on which you re operating. Hyper Memory will store not only frequency and tone data, but also Automatic Repeater
Shift status, Packet parameters, Scanning mode, and VFO tracking configuration.
The FT-8800 series lets you scan the memories, the entire operating band, or a portion of the band. The transceiver will stop on signals encountered during the scan, resuming the scan after a time delay or after the carrier drops out. During band scanning, you may configure the FT-8800 series to remain within the current band, or hop to the other band, once the band edge is reached. Dualfrequency "Priority Channel" operation is also provided. And the Programmable Memory Scan feature allows you to set up sub-band limits, so you won t waste time scanning or tuning in the SSB/CW portions of the bands.
Providing excellent performance even under difficult link conditions, Yaesu s 50-tone sub-audible CTCSS and 104-tone DCS signaling systems ensure that you have full access to repeater and remote-base inputs, and the built-in CTCSS/DCS decoders allow silent listening on busy channels. Plus you get Tone Search Scanning, which will scan for the tone being received on an incoming signal, allowing you to match tones
quickly when operating on a new repeater system.
Included in the FT-8800 series is Yaesu s exclusive ARTS feature which provides a "hand-shake" with
other ARTS-equipped stations during emergency work. If an "out-of-range" conditions exists with, for
example, a low-power hand-held unit, ARTS will alert the FT-8800 series user so the hand-held s operator can
be advised to move to a better location.
Four programmable keys on the microphone allow you one-touch access to your favorite command functions.
The commands available from the microphone replicate the corresponding front panel key functions, and include Band Change, VFO/Memory switching, Home Channel access, 1 MHz frequency steps, Power Output selection, Repeater Reverse, and CTCSS/DCS setup.
With the FT-8800 series and its optional YSK-8900 Separation Kit, mounting your radio is a breeze even in the tightest locations. The YSK-8900 includes a 20-foot (6 m) remote cable and mounting bracket for the front panel.
SMART SEARCH AUTOMATIC MEMORY LOADING
The Smart Search feature may be used to load automatically with no operator intervention a special memory bank of up to 25 memory channels per band on which activity is detected. Smart Search will sweep the band, looking for channels on which activity may be found, and will load busy channels into special "soft" memories.
For operating on FM satellites like UO-14, the versatile memory system of the FT-8800 series allows you to store a set of uplink and downlink frequencies that account for Doppler shift over the entire horizon-to-horizon pass, allowing you to select the optimum uplink/downlink combination effortlessly.
Convenient Access to WiRES and Other Internet-Linking Systems 1200/9600 BPS Packet Capability: Connect your TNC using the optional CT-39A Packet Cable Automatic Repeater Shift: Automatically sets the repeater shift within the designated repeater sub-bands RF Squelch: Opens the squelch at a user-defined S-Meter level Automatic Power-Off (APO): Turns radio off after long periods of inactivity Time-Out Timer (TOT): Prevents "Stuck Microphone" from causing lengthy QRM to others Battery Voltage Meter: Lets you know if your battery is getting low DTMF Auto-Dial Memory: 16 Memories of up to 16 tones each Lock Feature for Front Panel Keys & PTT Switch: Prevents accidental transmission or frequency change Built-in Duplexer
