> Tektronix TM504 4-slot mainframe w/SC503 DM501A AM502
Tektronix TM504 4-slot mainframe w/SC503 DM501A AM502
TEKTRONIX TM504 4-SLOT MAINFRAME W/SC503 DM501A AM502
SearchBy9 - 17379 | Location: Z19 | By: Nick | Tester: Peter | Quan: 1 | List: 1 | Duplicate? False | Plan: D (Single Item)
Sales: | Business & Industrial > Electrical & Test Equipment > Test Equipment > Oscilloscopes
TEKTRONIX SC503 OSCILLOSCOPE
TEKTRONIX DM501A DIGITAL MULTIMETER
TEKTRONIX AM502 DIFFERENTIAL AMPL
The TM504 is a 4 slot power chassis. The right hand slot is a high power slot for plug-in's like the PS 503 power supply. It weighs 21 lb.
The TM504 Power Module Mainframe accepts up to four single width TM 500 plug-ins. Each TM504 comes equipped with front panel switch, tilt bail, and a handle. The right hand compartment is a high-power compartment.
Tektronix SC503 10MHz Storage Oscilloscope.
The DM501A Multimeter Module measures DC voltage from 200 mA to 1000 V in 5 ranges. True RMS AC voltage ranges from 200 mV to 500 V. Resistance from 200-ohms to 20 Mohms in 6 ranges. DC and True RMS AC current 200 A to 2000 mA in 5 ranges. Temperature -62 C to +240 C.
The AM 502 is a dc-coupled differential amplifier with excellent common-mode rejection capabilities and high gain for low voltage measurements. The dc offset capability permits nulling up to 1 volt dc, so that low level, low frequency signals impressed on a dc level can be amplified without the degradation often introduced by ac input coupling. High and low frequency -3dB points can be selected at the front panel to suit the application. Signal inputs and outputs are available at the rear connector as well as at the front panel. A front panel lamp indicates most overrange conditions of excessive input signal, excessive gain, or excessive offset.
