Transistor development pcb with BC547 (#2045)
Transistor Development PCB with BC547 (#2045)
This is the Prototype Transistor PCB and BC547 Transistor Design Kit. This kit is what you need to develop numerous different transistor circuits. It includes the extremely useful Prototype Transistor PCB, which was designed by us, and some of the very popular BC547 NPN Transistors in the standard leaded TO-92 package. You will also get a blank Prototype PCB with 162 holes, also designed by us, to expand your circuits.
BC547, NPN, General Purpose Amplifier, TO-92
25K, Single-turn, Thru-Hole, PCB Mount
100K, Single-turn, Thru-Hole, PCB Mount
320K, Single-turn, Thru-Hole, PCB Mount
500K, Single-Turn, Thru-Hole, PCB Mount
5.0M, Single-Turn, Thru-Hole, PCB Mount
Red/Green, Dual Diffused, Rectangular, Thru-Hole
Red, Diffused, Thru-Hole, Radial
Green, Diffused, Thru-Hole, Radial
Yellow, Diffused, Thru-Hole, Radial
