Anritsu MW0972B sm fiber module for MW9070A otdr MW0972
Anritsu MW0972B SingleMode 1310nm/1550nm Module
For Use With The Anritsu MW9070A OTDR MainFrame
10/125 m SM fiber *ITU-T G.652
1310/1550 30 nm (typical: 15/20 nm)
FC, ST, DIN, SC, DIAMOND (HMS-10/A)
20, 50, 100, 500, 1000, 2000, 4000, 10000
36 dB at 1.31 m 34 dB at 1.55 m
22 dB at 1.31 m (typical: 25 dB), 20 dB at 1.55 m (typical: 23 dB)
Dead zone Back-scattered light
Distance measurements: 2 m (10 4 x distance) marker resolution *Excluding uncertainly caused by fiber IOR Loss measurements (linearity): 0.05 dB/dB or 0.1 dB (whichever greater) Return loss measurements: 4 dB
180 s max. (auto-measurement mode)
Laser: 21CFR Class 1, IEC Class 1
