Binocular stereo microscope w boom stand + 54 led light
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 1
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 2
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 3
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 4
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 5
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 6
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 7
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 8
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image 9
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image A
Boom Stand Binocular 10x~20x~30x~60x Stereo Microscope
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image R
XG326NHL54P Binocular Stereo Microscope with Boom Stand Image B
* High quality optical glass elements
* Sturdy boom stand provide extra working space and secure microscope head
* 54 LED cold ring light with 48 mm thread adapter
* 45 inclined 360 rotatable binocular head
* Sharp stereo erect images over a super wide field view
* Left ocular-tube diopter adjustment 5dp
* Interpupillary distance: 2-3/16" ~ 2-15/16"(55~75mm)
* Adjustable inter-pupillary distance to fit anyone's eyes
* Locked-in eyepieces avoid eyepiece dropping
* Capable to add auxiliary lenses and ring lights
* Diameter of ring light or auxiliary lens mount: 48mm female thread
Magnifications and Objectives:
* Eyepieces: wide field WF10X/20 and WF20X/10
* Objectives: rotational 1x & 3x
* Four magnification levels: 10x, 20x, 30x & 60x
* Working distance: 3-1/8" (80mm); working distance with optional 0.5x attachable objective: 4-3/4" (120mm) (0.5x auxiliary lens sold separately)
* Field of view: Maximum 3/4"(20mm)
* Metal rack and pinion mechanism
* Large and sturdy base secure microscope body
* 360 horizontal rotatable movement
* Body holder can be horizontally pan rotating
* Matching diameter for microscope body: 75-76mm
* Body holder dimension: 76mm+
* Body holder can flip up to 90
* Height of boom stand: 16~3/4" (42.5 cm)
* Boom travel stroke: 9~5/8" (24.5 cm)
* Base Dimension: 9 "x 9" (23 cm x 23 cm)
* 54 LED ring light with power adapter, adjustable intensity,100v-240v 50/60Hz worldwide power range
* 48 mm thread adapter included
* Dimension: 19-5/8 " x 18-1/2" x 14-1/2" (50 cm x47 cm x 36 cm)
* Binocular stereo microscope head
* A pair of WF10X/20 eyepieces
* A pair of WF20X/10 eyepieces
* A pair of rubber eyeshields
* A full set of universal boom stand with rack and pinion focus adjustment (A901)
* 54 LED ring light with power adapter
* 48 mm thread ring light adapter
Optional Accessories (sold separately):
* Fluorescent ring light for brighter even illumination
* Gooseneck fiber cold light for flexible lighting angles
* Fiber ring light with low heat and adjustable intensity
* Gem jewel tweezers (be used on a mechanical stage)
* 0.5X auxiliary objective for increasing working distance and field of view
* 2.0X auxiliary objective for having higher power levels
* USB camera eyepiece for computer connection
* Mechanical specimen stage for smooth movement
Click the button above to see compatible part list for this product XG326NHL54P
