Hendey lathe operator's manual 88-pages
Operators' Handbook for Hendey Lathes
This is a reproduction, not a photocopy, of an original Operators' Handbook for Hendey Lathes. This manual has been digitally cleaned and ENLARGED for easier reading and understanding of the charts without using a magnifying glass (I'm not kidding look at picture below). This is a LARGE 88 page manual that contains a lot of detail information. If you are fortunate enough to own one of these lathes, this is a must have for you. This manual covers a lot of the unusual attachments that this lathe offered. There is a large section on threading. It has copies of all standard threading index plates showing normal ranges of threads and feeds. This manual covers the lathe from A-Z in great detail, and that is why it is 88 pages. This is an very interesting manual to own if you collect old manuals.
Some of the Unusual Attachments
Original (Front) Reproduction (Back) Notice that you can actually read mine.
