Mitsui 818 super precision hand feed surface grinder
MITSUI 818 SUPER PRECISION HAND FEED SURFACE GRINDER
8" X 18" MITSUI "SUPER-PRECISION" (MADE IN JAPAN)
MODEL: MSG250-MH S/N: 91115638 NEW: 1991
TABLE WORK SURFACE ................. 8" x 19"
LONGITUDINAL TABLE MOVEMENT ........ 20"
CROSS TABLE TRAVEL ................. 10"
HEIGHT, TABLE TO SPINDLE CENTER .... 20"
GRINDING WHEEL ..................... 8" DIA. MAX.
APPROX. WEIGHT ..................... 2,200 LBS.
HAND FEEDS WITH VERY LOW FRICTION & EASE OF USE
ALL 3 AXES ARE ROLLER BEARING SLIDES
HARDENED & GROUND WAYS (REMOVEABLE) ON TABLE,
TABLE, SADDLE & COLUMN MOVE ON LINEAR BALL BEARINGS
AUTOMATIC ONE SHOT LUBRICATION SYSTEM
1.3 HP 3/60/220 VOLT SUPER-PRECISION SPINDLE DRIVE
8" X 18" O.S. WALKER "FINE-DIVISION" "TRANSVERSE POLE"
"VAC-U-GUARD" WHEEL COVER FOR MORE EFFECTIVE GRINDING GRIT
GRAYMILLS COOLANT TANK, 24" L x 10 W x 12" H TANK
1/8 HP/110 VOLT/1 PHASE COOLANT UMP
MACHINE IS WIRED FOR 3/60/460 VOLTS
