20" x 40" mark (proth) 3 axis automatic surface grinder
20" x 40" MARK (PROTH) 3 AXIS AUTOMATIC SURFACE GRINDER
20" x 40" MARK "HEAVY DUTY" COLUMN TYPE
(MADE BY PROTH) (ALSO SOLD BY SHARP)
ADDED TO MACHINE IN 2007 BY FACTORY
MODEL : 2040 S/N: 0108J-01 NEW: 2001
WIDTH & LENGTH GROUND ....................... 20" X 40"
CROSS TRAVEL .................................... 20.9"
LONGITUDINAL TABLE TRAVEL ....................... 47"
SPINDLE CENTER TO TABLE SURFACE ................. 27.6"
CONTINUOUS CROSS FEED (BALLSCREW) ............. 39" IPM
FEED PER REVOLUTION ............................ 0.200"
NO. OF GRADUATIONS ON DIAL ........................ 100
FEED PER REVOLUTION ............................ 0.010"
RAPID DOWNFEED (OPTIONAL) .................... 11.8 IPM
WHEEL SIZE (OD X WIDTH X ID) ............. 14" X 2" X 5"
SPINDLE MOTOR ................................... 10 HP
COOLANT SYSTEM MOTOR ........................... 1/8 HP
APPROXIMATE WEIGHT ......................... 16,000 LBS
APPROXIMATE DIMENSIONS (W X D X H) ..... 180"L-R x 90"D
MODES) ..... INSTALLED NEW IN 2007.
20" X 40" ELECTRO-MAGNETIC CHUCK W/NEUTROFIER CONTROL
** NEW!, NEVER USED! - WOW! **
** INSPECT IN OUR HARRISON, NJ FACILITY **
