New jet 13" x 40" 3 hp geared head engine lathe 321810
Spindle Mount D1-4 Number Of Spindle Speeds 12 Range Of Spindle Speeds 40 - 1,800 RPM Range Of Inch Threads 4 - 112 TPI Number Of Inch Threads 40 Range Of Longitudinal Feeds .0012 - .0294 in./rev. Range Of Cross Feeds .0003 - .0103 in./rev. Spindle Taper W/ Sleeve MT-5 (MT-3) Taper In Tailstock Spindle MT-3 Net Weight 2,081 lbs. Motor 3 HP; 1 Ph 230V Spindle Bore 1-1/2-in Distance Between Centers 40-in Width Of Bed 10-1/2-in Swing Over Bed 13-in Swing Through Gap 19-in Compound Slide Travel 3-1/2-in Cross Slide Travel 6-3/8-in Swing Over Cross Slide 7-1/2-in Number Of Longitudinal And ; Cross Feeds 40 Maximum Tool Size 5/8-in x 5/8-in Carriage Travel 37-1/2-in Tailstock Spindle Travel 4-3/4-in Steady Rest Capacity 3-3/4-in Follow Rest Capacity 2-3/4-in Overall Dimensions 73-3/4-in x 29-1/2-in x 47-1/2-in
