Digital oscilloscope 100MHZ 1G sr 2M/ch 3YRS warranty
New Portable Digital Storage Oscilloscope 100Mhz ADT1102CA, 1G sample rate, 2M memory depth/channel
Brand New with three years warranty
3.Industry controlling measure
The volume exquisite and it is convenient for carrying
Screen saver function 1 minute to 5 hours
Dual channel-channel bandwidth: 100MHZ.
The real time sampling rate is 1GSa/s.
Trigger Modes: Edge, Pulse, Video, Slope and Alternative trigger modes.
Support Multilingual online help system.
The Common Specifications Of All ADT1000 Series Products
The highest capture rate exceed 1000 times/sec
Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Cmean, Mean, Vrms, Crms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Freq, Period, Rise time, Fall Time, +Width, -Width, +Duty, - Duty, BWid, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Window: Hanning Hanmming Blackman Rectangular
Support the sampling rate : 5KSa/s 1GSa/s (in a 1-2-5 sequence)
Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Spanish, Portuguese, Japanese, Korean, Italiana
(X1, X10)Problex2, EasyScope3.0 Computer Software System, Power Cord, USB cable, User Manual, EasyDsoLib software package,
EasyScope3.0 software can connect the ADT1000 series DSO to the PC through USB serial interface or RS-232 interface
The software can afford controlling and analyzing function such as following items:
1:Display the captured waveforms, data and measurement value by the display areas.
2:Control the local and distant operation by the DSO controller.
3:Save the picture as BMP format
4:Save the data to EXCEL file, easy to analyzer
*EasyDsoLib Software development kit
1) 2 units of 100Mhz X1 X10 probes:
Brazil, South Africa, Argentina, Chile, Colombia, Costa Rica, Cuba, Turkey, Poland, Romania, Russia, Slovakia, Ukraine, India, Pakistan, Czech republic and so on
