> Great worksheet for pipefitter pipe fitter steamfitter
Great worksheet for pipefitter pipe fitter steamfitter
Great worksheet for pipe fitter / stream fitter / welder / plumber in the piping construction
This Worksheet makes the work more simply, more exact and also faster.
You become a better pipefitter whether 1 month or 20 years professional experience.
You will faster and more accurate with less work.
The worksheet is for each pipefitter an assistance.
Very easy to calculate from offsets with a finished elbow length and much more.
It is always in the trouser pocket and the pipefitter has all important information for the practical work and the allocation of the materials always locally.
(8.5x11inch double sided imprinted, laminated against dirt, on pocket size folded 6,1 x 4,4 inch, for daily use on the site, handbook size)
Everything at a glance, no search in the handbook.
It contains the following data:
- Nominal pipe size and outside diameter / - 42 inch
- Length of butt weld 5 - 90 long radius (1.5D) elbow (welded) / 42 inch
Calculate of offsets and cut elbow:
- factor for the offset calculation of 5 - 90 in 2,5 steps
- 2 examples for the calculation of offsets with pipe (inclusive drawing)
- 2 formulas for the calculation of offsets without pipe (inclusive drawing and key sequence for the calculator)
- Calculation of exactly cut to the elbow (inclusive drawing and key sequence for the calculator)
- Drawing to hot bending of little pipe
- Length of elbow (5 - 90 ) - 42 inch
- Length if reducer - - 20 inch
- Length of tee and reducer tee / - 20 inch (inclusive drawing)
- Dimensions of flanges (150lb/300lb) as overall length, number of bolts, large of bolts, diameter of bolts, Gaskets outside diameter (ring and full face) and minimal wall distance of flange pipe / - 20 inch
Rules in the pipeline construction:
- Dimensioning to the vent- and draining line / - 20 inch
- Pipe volume / - 20 inch (for pressure probe or gas purging)
- Pipe insulation / - 20 inch
- Comparison nominal pipe size to DIN / - 20 inch
This worksheet is a BIG HELPER for pipefitter and steamfitter.
For me this worksheet is one of the basic equipment like the tape measure.
delivery from germany (3-7 days)
