> 1XHIGH-power 20W warm white led brightness 1000LM 14V y
1XHIGH-power 20W warm white led brightness 1000LM 14V y
1xhigh-power 20w warm white led brightness 1000LM 14v Y
Long service life(Intensity remain above 70% after work 100,000H)
Each color for your selection (red ,yellow , green , blue , white, warmed white)
DC Forward Voltage (VF): 13.5 ~ 15.0 V
*Absolute Maximum Ratings at Ta=25Degrees:
Peak pulse current(1/10 duty pulse width 1msec)
* Electrical/Optical Characteristics at Ta=25Degrees:
*Electrical & Optical Curves at Ta=25Degrees:
2 Use IPA as a solvent for cleaning LED products, the other solvent may dissolve the LED package and the epoxy, Ultrasonic cleaning should not be done.
n Open circuit , short circui ,leak current overpass , turn on voltage becomes lower ,Inadequate intensity supplied.
Our 20w leds need cooling board to avoid the extra heat. Pls use the 20w led as the product specifications , If improper operation caused led burning out, we won't be responsible for it .
