Fox 0109 windrow pickup header operator & parts manual
Fox Model 0109 Windrow Pickup Head Operator/Parts Manual
This 24-page parts & operator manual has illustrated parts listings for these heads, with exploded views, part number, and part description. Also indexed by part number. Includes instructions for operating, adjustments, setup & initial assembly, and lubrication.
This manual has minor wear marks on the covers. Inside pages are clean. Manual doesn't appear to have ever been used much, if at all. No rips or tears. Front cover is loose from the manual. Nothing missing. Still perfectly usable and readable.
