High power mini pci wireless lan ieee 802.11A 150MW
High Power Mini PCI Wireless LAN Card150mW IEEE 802.11a - All new!
-70 dBm @54Mbps Rx Sensitivity
Hirose U.FL Antenna Connector
32-bit mini-PCI Type III B Interface
MAC / Baseband - Atheros AR5213
Driver support Windows, Linux and customized drivers are available.
Supply Voltage 3.3 Vdc, +/- 5%
Supply Voltage Ripple 120mV (pp) max.
Sleep-to-receive startup time <75 ms
Power consumption TX: <1000mA, RX: <400mA,
Antenna Connector Specification :
Connector Type Hirose U.FL 50
Manufacturer Hirose Electronic Co. Ltd.
Part Number U.FL-R-SMT (CL331-0471-0-01)
Working Temperature 0 ~ 55 C, 95% relative humidity (non-
Storage Temperature -20 ~ 80 C, 95% relative humidity (non-
Mean Time To Failure is rated at 150,000 hours.
The XA-622H interoperates with any IEEE 802.11a compliant devices.
The XA-622H supports WPA / WPA2 and IEEE 802.1X. Support will be equal to or
greater than the latest Atheros supplied driver. See driver for full details.
