Leader lbo-523 oscilloscope dual-trace 35 mhz works
We have tested this scope with a multimeter and found both input channels 1 and channel 2 to operate correctly. We do not guarantee correct calibration.
In the photographs below, you can see the cosmetic condition of this item. Also pictured below, you will see a photograph showing a waveform pattern. This waveform is generated by a function generator (NOT INCLUDED) set to 5KHz, 1 volt. The scope is set on 0.5 V/Div, and 50 s/Div. The second line is generated by 0 input on channel 2 to show that channel 2 displays.
