19.75" swg 20" cc kellenberger 600 urf od grinder, extr
19.75" Swg 20" cc Kellenberger 600 URF OD GRINDER, EXTR
19.75" Swing 20" Centers Kellenberger 600 URF OD GRINDER, EXTRA HEAVY WKHD., LIVE SPINDLE, TAILSTO
19.8" X 20" KELLENBERGER "SWISS" "HIGH-PRECISION"
UNIVERSAL I.D./O.D GRINDING CYLINDRICAL GRINDER
** "URF" SERIES MACHINE - EXTRA HEAVY WORKHEAD CAPACITY
(3,000 INCH POUNDS INCLUDING FIXTURE), LARGE SWING
(19- 3/4") MAKES THIS MACHINE UNUSUAL & EXTREMELY
DESIREABLE, ESPECIALLY PARTS THAT NEED TO CHUCKED.
INDUSTRIES SUCH AS AEROSPACE, ROLLER BEARING
& TOOL & DIE SHOPS WILL FIND THIS MACHINE PARTICULARLY
MODEL: 600 URF S/N: 1677/455 NEW: 1980
MAXIMUM SWING IN GAP ......................... 19- 3/4"
LENGTH OF GAP FROM FACEPLATE TO TABLE WORK
SURFACE ..................................... 10"
CENTER DISTANCE FROM TABLE TO TAILSTOCK
CENTER ....................................... 8- 1/4"
DISTANCE BETWEEN CENTERS (APPROXIMATE)......... 20"
GRINDING WHEEL SPEEDS ..... (3) 1530, 1750, & 2,040 RPM
INFINIT. VARIABLE SPINDLE SPEEDS ........ 5 - 500 RPM
WORKHEAD MOTOR ............................... 2.2 KW
APPROXIMATE MACHINE WEIGHT .................. 7,000 LBS
16" X 2" X 5" O.D. GRINDING WHEEL
-INTERNAL GRINDING SPINDLE, 3" CUP WHEEL, WHEEL COLLET TYPE
-12" DIAMETER "ECLIPSE" MODEL AX12C (MADE IN ENGLAND)
MAGNETIC CHUCK MOUNTED ON FACE PLATE
-TAILSTOCK HAS OPTIONAL FINE ADJUSTMENT FEATURE FOR TAPER
-COOLANT SYSTEM w/MAGNETIC SEPERATOR, 48" X 19" X 13"H TANK
SPECIAL FEATURES TO "URF" SERIES:
WORKHEAD WITH "LIVE" WORKHEAD SPINDLE, EXTRA HEAVY DUTY
DESIGN THAT ALLOWS PERMISSABLE LOAD CAPACITY OF
3,000 INCH POUNDS. WORKHEAD SWIVEL RANGE IS 360 DEGREES,
WITH FINE ADJUSTMENT OF +/- 2 DEGREES BY HANDWHEEL.
** VERY NICE CONDITION & APPEARANCE **
