Tektronix CMD80 w/ all otpions, 90 day warranty
Unit is tested and working, comes with a 7 day right to return.
This unit has ALL OPTIONS installed:
* CMD-B1 - High-stability reference oscillator
* CMD-B3 - Multireference frequency Inputs/Outputs
* CMD-B14 - 13k vocoder rate (14.4k data rate)
* CMD-B60 - Adapter for B61 and B62
* CMD-B61 - IEEE Bus Interface
* CMD-B62 - Memory Card Interface
* CMD-B81 - Additive White Gaussian Noise (AWGN) generator
* CMD-B84 - IS-136 (D-AMPS) Test Capabilities
* CMD-K1 - Adds cellular operation
* CMD-K2 - Adds PCS operation
Additional capability continues to be added to the proven CMD80 platform. In addition to CDMA, AMPS (N-AMPS) and TACS (J/N/E-TACS), digital AMPS (IS-136) measurements on mobile stations are now possible with option B84. CMD80 is thus able to support all multiple access methods presently used in mobile communications (FDMA, CDMA, TDMA) on a single hardware platform.
* High measurement accuracy and repeatability
* High reliability and quality
* Triple mode (CDMA, TDMA, Analog) dual band (cellular, PCS) in one box
* Remote control via IEEE488/IEC625 bus
* Autotest - complete mobile testing at a keystroke
* Remote control via GPIB or RS232
* Suitable for production, development and service
* Very fast remote control operation
* Voice lookback and comprehensive testing of mobiles
* Powerful signaling capabilities
* Simple interactive operation
