Hp 8902A measuring receiver w/11793A, 11722A, 11792A
Measuring Receiver with Microwave Converter & Sensors
Measuring Receiver Model#: 8902A
Microwave Converter Model#: 11793A
Sensor Module Model#s: 11722A & 11792A
Delivers the accuracy and resolution of a high performance power meter at frequencies from 150kHz to 1.3GHz (50MHz to 26.5GHz with the 11793A microwave converter) and levels from +30dBm to -127dBm. It accurately measures AM, FM and M, including residuals and incidentals, with a single keystroke. The 8902A measuring receiver, with the 11793A, counts RF signals to 26.5GHz with 10Hz resolution and excellent long-term frequency stability.
RF power: digital power meter accuracy
Tuned RF level: 0 to -127dBm dynamic range
Carrier noise: AM and phase noise measurements to -140dBc/Hz
AM and FM: 1% accuracy; Phi-M:3% accuracy
RF frequency: 1Hz resolution
Audio: level, frequency, and distortion
Downconverts microwave signals to the frequency range of the 8902A measuring receiver. For signals above 1.3GHz, the 11793A routes the signal through its internal mixer. Below 1.3GHz, signals are routed directly to the input of the 8902A. The 11793A requires +8dBm leveled output from the local oscillator. Has option 011: for LOs with insufficient power above 18GHz, the 11793A offers an optional 18 to 26.5GHz amplifier.
Frequency Range: 100kHz to 2.6GHz
Power Range: +30dBm (1 watt) to -20dBm (10 W)
Input SWR (connected to an HP 8901B or 8901A): <1.15, for RF power measurements
Power sensor linearity: +2%, -4%; +30dBm to +20dBm; negligible deviation, levels <+20dBm
Frequency range: 50MHz to 18GHz
Measurement range: 10 W to 1W (-20dBm to +30dBm)
Has option 001: Type-N connector; limits frequency to 18GHz
Working lab standards. Offered with 30-day warranty.
Accessories: manuals (on CD), 11793-60006 IF input cable, 11793-60009 LO input cable, 3.5mm/Type-N adaptor, two power cords.
