11" y 18" x moore #3 jig grinder, 2X dro, hard ways & s
11" Y 18" X Moore #3 JIG GRINDER, 2X DRO, HARD WAYS & S
11" Y Axis 18" X Axis Moore #3 JIG GRINDER, 2X DRO, HARD WAYS & SCREWS,
** CERTIFIED WITH AN ACCURACY REPORT PERFORMED
BY JOE LAWRESKO SR. OF J & L MACHINE REPAIR.
JOE HAS OVER 20 YEARS EXPERIENCE REFURBISHING
& CALIBRATING MOORE JIG GRINDERS.
WE CAN FAX YOU JOE'S REPORT OR YOU CAN
TABLE SIZE .................................... 11" X 24"
TABLE MOVEMENT ................................ 11" X 18"
TABLE TOP TO WHEEL COLLET ...................... 2" X 18"
SPINDLE TO COLUMN WAYS .............................. 10"
SPINDLE TO COLUMN BELOW WAYS .................... 13-1/2"
INFINITELY VARIABLE SPINDLE SPEEDS ........ 40 TO 250 RPM
INFINITELY VARIABLE SPINDLE FEEDS .......... 2 TO 120 SPM
GRINDING WHEELS ............................. 3/16" TO 5"
DIAMOND MANDRELS ......................... 1/64" TO 3/16"
MAIN SPINDLE SLIDE ADJUSTMENT ................ 1-1/2 DEG.
APPROXIMATE WEIGHT .......................... 3,700 LBS
APPROX. FLOOR SPACE REQUIRED .... 72"LR X 84"FB X 102"H
2-AXIS DIGITAL READOUT DISPLAY (.0001" RESOLUTION)
HARDENED, GROUND & LAPPED LEAD SCREWS
1/2 HP VARIABLE DC MOTOR WITH RECTIFIER
(1) MOORE JIG GRINDING HEAD (60,000 RPM)
** INSPECT IN OUR HARRISON, NJ WAREHOUSE **
