Hartex Tool & Radius Grinder Model 3 Tangent-Arc
Hartex Tool & Radius Grinder
Model No. 3 Tangent-Arc Profile
Maximum Length of Flute: 5-1/2"
Max. Diameter Held Between Centers: 4-3/4"
Max. Length Held Between Centers: 10"
Max. Concave Radius: 5-1/2"
Max. Convex Radius: 5-1/2"
Main Wheelhead Slide Travel: 5-1/2"
Wheelhead Transverse, Quick Adjustment: 6-3/4"
Wheelhead Transverse, Fine Adjustment: 3-1/4"
Total Wheelhead Transverse Travel: 9"
Rotary Movement of Work Table: 210 Deg.
Parallel to Cutter Axis, Fine Adj.: 3-1/4"
Parallel to Cutter Axis, Quick Adj.: 6"
Parallel to Cutter Axis, Total: 9-1/4"
Normal to Cutter Axis Quick Adj.: 10"
Normal to Cutter Axix, Fine Adj.: 2-3/4"
Normal to Cutter Axis, Total: 12-3/4"
Vertical Movement or Work Holder: 2-3/4"
Grinding Wheel Size: 6" Dia. x 3/4" Face
1/2 HP Spindle Motor 115/230/1/60
Approximate Net Weight: 1,000 lbs.
